This is a module cloning service. You will need to provide us with the original module you are hoping to have cloned as well as your donor module. Your donor module should be of the same part number as your original module otherwise there is a high probability that we will not be able to clone your module successfully. Each module must be clearly labelled which is the original and which is the donor.
If you're looking for our repair service for this module you can find it here.
Details specific to this module's cloning service
On the 2005-2007 Ford F550 Instrument Cluster we are able to make a close to full duplicate of your original instrument cluster. That means all of the following data can be transferred from your original instrument cluster:
-Odometer
-Engine Hours
-AsBuilt Data(Vehicle Specific Configuration/Coding of your module)
-Firmware Version
As far as your vehicle will be able to tell the cloned module will be effectively identical to your original module. To ensure full compatibility of donor module you'll want to be sure that you follow this guide when finding a replacement module.
Which vehicles does this module cloning service apply to?
This cloning service applies to the following vehicles:
2005 Ford F550
2006 Ford F550
2007 Ford F550
What part numbers of modules does this cloning service apply to?
The below list is by no means exhaustive, meaning we might not have all of the applicable part numbers listed. In the case that you don't seen your part number listed don't hesitate to give us a call. However these are the part numbers that we've confirmed this cloning service applies to:
5C3T-10849-BF
5C3T-10849-BG
5C3T-10849-CH
5C3T-10849-CJ
5C3T-10849-DF
5C3T-10849-DJ
5C3T-10849-FA
5C3T-10849-FG
5C3T-10849-FH
5C3T-10849-FJ
5C3T-10849-GH
5C3T-10849-GL
5C3T-10849-HJ
5C3T-10849-HK
5C3T-10849-HL
5C3T-10849-RG
5C3T-10849-RJ
5C3T-10849-SC
5C3T-10849-SG
5C3T-10849-SJ
6C3T-10849-AA
6C3T-10849-AM
6C3T-10849-BA
6C3T-10849-BM
6C3T-10849-CA
6C3T-10849-DA
6C3T-10849-DC
6C3T-10849-DD
6C3T-10849-DE
6C3T-10849-EA
6C3T-10849-EC
6C3T-10849-ED
6C3T-10849-FA
6C3T-10849-FC
6C3T-10849-FD
6C3T-10849-FE
6C3T-10849-GC
6C3T-10849-HA
6C3T-10849-HC
6C3T-10849-HD
6C3T-10849-JA
6C3T-10849-JC
6C3T-10849-JD
6C3T-10849-JE
6C3T-10849-KA
6C3T-10849-KC
6C3T-10849-KD
6C3T-10849-KE
6C3T-10849-KF
6C3T-10849-MB
6C3T-10849-MD
6C3T-10849-NC
6C3T-10849-PA
6C3T-10849-PC
6C3T-10849-PD
6C3T-10849-PE
6C3T-10849-UD
6C3T-10849-VA
6C3T-10849-VD
6C3T-10849-ZA
6C3T-10849-ZB
6C3T-10849-ZC
How are the modules cloned?
Individual modules will always require unique and different approaches to cloning, which leads to us having to utilize many different methods for cloning your modules. In ideal situations we're able to take full reads of the flash of your module's microcontroller as well as reads of your persistent data that can either be stored in a dataflash within your original module's microcontroller or an external memory device on your module's circuit board such as an EEPROM. We can then take that information and write it into your donor module, creating an identical clone of your original module as far as your vehicle can see. This method allows us to copy the information from your original module even if it is only partially working and in most cases we can even clone non-working modules.
In the case of many modern modules there are additional levels of security that prevent reading of your original module's flash or dataflash from it's microcontroller. In order to clone these modules we often find that we can't make an exact duplicate of your original but rather we instead focus on ensuring that we can get the information that OEM and even advanced aftermarket diagnostic tools are unable to program. This will leave you with a module that is able to be paired to your vehicle using an OEM diagnostic tool.
All modules are repaired on-site at our West Kelowna, British Columbia facility.
Why use Kelowna Instruments for module cloning?
Unlike most other module cloning services that simply purchase tools to allow them to clone a given module, Kelowna Instruments is one of the few companies that makes the tools that we use for cloning. This allows us a higher level of capability and understanding of modules that we offer cloning services for than any other provider of module cloning services. As we also produce diagnostic tools that we use in our repair services we're far more experienced when it comes to compatibility issues with your modules and can help to minimize or correct many of the compatibility issues that would prevent other cloning services from cloning your module.
What if my module can't be cloned?
If your module is unable to be cloned our technicians will contact you with more information and recommendations regarding a path forward.
Warranty
There is no warranty to module cloning. Customers are expected to provide a working module to use as a donor.
